Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Meanwell
  • Model Number: LRS-150-15
  • Output Power: 150W
  • Output Type: Single
  • Input Voltage: 85 ~ 132VAC/170 ~ 264AC by switch 240-370VDC (switch on 230VAC)
  • Output Voltage: 15V
  • Output Frequency: N/A
  • Output Current: 10A
  • Product Name: Most economical Mean Well 150w 15v 10a ac dc power supply LRS-150-15
  • Protection: Short Circuit/Overload/Over voltage
  • Working Temp.: -30 ~ +70°C
  • Efficiency: 88.5%
  • Voltage Adj. Range: 13.5 ~ 18V
  • Over Voltage: 18.75 ~ 21.75V
  • HS Code: 8504401400
  • Dimension: 159*97*30mm (L*W*H)
  • Packing: 0.48Kg ; 30pcs/15.4Kg/0.75CUFT
  • Warranty: 3 Years

Packaging & Delivery

Packaging Details Most economical Mean Well 150w 15v 10a ac dc power supply LRS-150-15 package details:
0.48Kg ; 30pcs/15.4Kg/0.75CUFT
Delivery Time 1-3 days

Model No.: Most economical Mean Well 150w 15v 10a ac dc power supply LRS-150-15

Product Description

Features:

Meanwell LRS-150-15 150W single output power supply

· Universal AC input/Full range
· Withstand 300VAC surge input for 5 second
· No load power consumption<0.5W
· Miniature size and 1U low profile
· High operating temperature up to 70℃
· Protections: Short circuit/Overload/Over voltage
· Cooling by free air convection
· Compliance to IEC/EN 60335-1 (PD3)and IEC/EN61558-1, -2-16 for household appliances
· Operating altitude up to 5000 meters
· Withstand 5G vibration test
· High efficiency, long life and high reliability
· LED indicator for power on
100% full load burn-in test
· 3 years warranty

Applications:

· Industrial automati on machinery
· Industrial control system
· Mechanical and electrical equipment
· Electronic instruments, equipments or apparatus
· Household appliances

Descriptions:

LRS-150 series is a 150W single-output enclosed type power supply with 30mm of low profile design. Adopting the input of 115VAC or 230VAC (selectable by switch), the entire series provides an output voltage line of 12V,15V, 24V, 36V and 48V.

In addition to the high efficiency up to 90%, the design of metallic mesh case enhances the heat dissipation of LRS-35 that the whole series operates from-30℃ through 70℃ under air convection without a fan. Delivering an extremely l0w no load power consumption (less than 0.5W), it allows the end system to easily meet the worldwide energy requirement. LRS-35 has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as TUV-1 EN60950-1, EN60335-1, EN61558-1/-2-16, UL60950-1 and GB4943. LRS-150 series serves as a high price-to-performance power supply solution for various industrial applications.
